COOLER FAN TRANSPARENT CLEARSTAR 140 140x140x25mm SPIRE SP14025NTL3 NANO TECH BEARING 12V (PC)

CLEARSTAR 140

The ClearStar fan series are silent fan models resulted from years of experience in designing thermal products for the PC and IT industry. Engineers at Spire have created the ClearStar fans to supply sufficient airflow under silent circumstances. The ClearStar fan series contain a new shape of impeller blades and spokes that hold the fan motor. The impeller is elevated to create a greater air intake and to reduce the resistance of spokes which sometimes can cause a high-pitched sound. Build with the proprietary Nano-Tech bearing, Nano-Tech bearing is less friction, easy to start up that will make this fan will spin for a very long time and it will do so silently.

Package Dimension (cm) 15 x 16 x 2.8

Release Date 10 / 16 / 2015

Unit Weight 145g

Unit Dimension (cm) 14.00 x 14.00 x 2.50

AirFlow (CFM) 96

Application

case fan, system fan, consumer electronic cooling and home appliance cooling

Bearing Type Nano Bearing

Certification CE/RoHS/REACH

Color Transparent

Connectors 3 PIN Molex 2510

Fan Size (cm) 14 x 14 x 3

Fan Type DC12V Nano-Tech

LED Color None

Life Expectancy (HRS) 70000H

Material PE

Noise Level (dBA) 21 ~ 22

Operating Temperature (°C) -20 to 70

Packaging Includes

ManualWarranty

information

4 metal mounting screws

Packaging Type Retail box

PWM(Pulse Width Modification) No

Rated Current (A) 0.2

Rated Power (W) 2.4

Rated Speed (RPM) +/- 10% 1500 ~ 1500

Static Pressure mmH2O 1.80

Storage Temperature (°C) -40 to 70

Voltage AC (INPUT) 12V

Warranty 2 years
