2Tb Σκληρός Δίσκος Εσωτερικός Toshiba Hard Disk Drive SATA 3.5 MD03ACA200V

Basic Specifications

Interface : SATA-2.6 / 3.0

Interface Speed : 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit/s

Formatted Capacity 4 TB 3 TB 2 TB

Logical Data Block Length ( HOST ) : 512 B

Logical Data Block Length ( DISK ) : 512 B

Environmental Compliance RoHS Compatible

Performances

Buffer Size : 64 MiB FIFO ring buffer

Rotation Speed : 7,200 rpm

Average Latency Time 4.17 ms

Reliability

Unrecoverable Error Rate : 1 per 1014 bits read

Power Requirements

Supply Voltage : 5 V ±5 % , 12 V ±5 %

Power Consumption ( Read / Write )  : 11.3 W

Power Consumption ( Low Power Idle )  : 6.0 W Typ.

Dimensions

Height : 26.1 mm

Width : 101.6 mm

Length : 147 mm

Weight : 720 g Max.

Environmental Requirements

Enclosure surface temperature

( Operating ) 0 to 70 °C

Temperature ( Non-operating ) -40 to 70 °C

Humidity ( Operating ) 5 to 90 % R.H.

Humidity ( Non-operating ) 5 to 90 % R.H.

Altitude ( Operating ) -305 to 3,048 m

Altitude ( Non-operating ) -305 to 12,192 m

Vibration ( Operating ) 7.35 m/s2 { 0.75 G } （ 5 to 300 Hz ）

2.45 m/s2 { 0.25 G } （ 300 to 500 Hz ）

Vibration ( Non-operating ) 49 m/s2 { 5.0 G } （ 5 to 500 Hz ）

Shock ( Operating ) 686 m/s2 { 70 G } ( 2 ms duration )

Shock ( Non-operating ) 2,940 m/s2 { 300 G } ( 2 ms duration )

Acoustics ( Sound Power )

Ready 31 dB Typ.
